Start building your product.
Specify your options and generate a personalized spec sheet.
FEATURES & BENEFITS
- Narrow and wide flood, asymmetric optics
- Up to 4500lm in either direction
- Soft direct optic available
- Smooth light distribution for clean facade lighting and wall washing
- 4” x 9”x 8”
- ADA compliant
- A true asymmetric with high-efficiency optics
- Efficacy up to 125 lm/W
- Handcrafted in USA
SPECIFICATIONS
- LIGHT SOURCE: White LED light engine
- CRI: 80+ or 90+
- ORIENTATION: Indirect and direct
- LUMEN MAINTENANCE: L85 = >72,000 Hrs at 35°C ambient temperature
- EFFICACY: Up to 125 lm/W delivered
- CCT: 2700K, 3000K, 3500K, 4000K, 5000K
- VOLTAGE: 120-277V standard
- DRIVER: Includes integral Class 2 power supplies
- MAX AMBIENT OPERATING TEMP: 40°C (95°F)
- DIMMING: 0-10V controls standard
- CONTROLS: Contact factory for control options (e.g., Lutron Athena, Current NX, nLight, Enlighted, Encelium, Wattstopper, WaveLinx, or Casambi).
- EMERGENCY: Remote battery option is provided with 10W Constant Power Battery Back-up, providing 90 minutes of emergency operation. Contact factory for other emergency options.
- CONSTRUCTION: Aluminum construction; precision injection molded optics
- FINISH: Choose from 22 standard thermoset polyester powder coat paint colors or various metal finishes. RAL®, Pantone®, or custom finishes available upon request.
- MODIFICATIONS: Consult factory for all modification requests.
- APPROVALS: ETL listed to UL standards (US & Canada) for use in wet locations.
