FEATURES & BENEFITS

• A forward throw optic, for even wall wash illumination, is standard
• Symmetrical optic options are available for more volumetric illumination
• Lamp body can be rotated and locks into position for precise fixture alignment
• Up to 1,450 lumens per foot delivered (with Forward Throw distribution)
• Anodized finish provides durable corrosion protection
• Handcrafted in USA, BABA Compliant

SPECIFICATIONS

• LIGHT SOURCE:  White LED light engine
• CRI: 80+ or 90+
• LUMEN MAINTENANCE:  L70 = >50,000 Hrs.
• EFFICACY:  102 lm/W delivered (with Forward Throw distribution)
• CCT:  2700K, 3000K, 3500K, 4000K, 5000K
• VOLTAGE:  120-277V standard
• DRIVER:  Includes one remote Class 2 power supply and enclosure, except 8FT-L113W which has two.  36" lead length standard; black power cord standard unless otherwise specified.  Max distance to the driver is: #18 AWG = 50', #16 AWG = 75', #14 AWG = 100'. For extended distances, contact factory.
• DIMMING: 1% minimum dim level standard
• CONTROLS: 0-10V standard. Lutron Athena, Current NX, and nLight AIR optional. Contact factory for other controls (e.g., Enlighted, Encelium, Wattstopper, WaveLinx, or Casambi)
• EMERGENCY: Remote battery option is provided with 10W Constant Power Battery back-up, providing 90 Minutes of Emergency operation.  Contact factory for other Emergency options.
• INTEGRATED SURGE PROTECTION:  LED components are protected against minor surge events
• CONSTRUCTION:  Extruded aluminum construction provides durable protection for internal components and is recyclable
• FINISH:  Housing available in anodized finishes only. End caps and mounting components painted to match.
• MODIFICATIONS: Consult factory for all modification requests, including RGB and static LED colors
• APPROVALS: ETL listed to UL standards (US & Canada) for use in damp locations; not recommended for exterior applications
