CPS12153 5.00 in
Novato Lines + Arcs
This power drop kit is specifically designed for the Novato Lines + Arcs system. It includes the canopy and cord.
Novato Lines + Arcs CPS12153

Start building your product.

Specify your options and generate a personalized spec sheet.

FEATURES  & BENEFITS

  • One power drop required for every circuit

SPECIFICATIONS

  • VOLTAGE: 120-277V standard
  • POWER CORD: White power cord supplied compatible with Novato Lines + Arcs luminaires.
  • FINISH: Canopy is painted Super White (PT01); contact factory for alternate finishes
  • MOUNTING: Mounts to a standard 4" octagonal junction box; aircraft ceiling coupler (supplied with Novato unit) can be connected to the power drop canopy to gain flexibility in mounting
  • APPROVALS: ETL listed to UL standards (US & Canada) for use in damp locations; not recommended for exterior applications

DIMENSIONS

Dimensions
H
0.3 in
0.8 cm
D
5 in
12.7 cm
OAH
48 in
121.9 cm
Mounting Weight
Consult Factory.
